VE Distributor Valve

A typical VE distributor valve consists of a "first piece", a "tail piece" and 3 to10 working pieces. Can provide 3 to 20 lubrication points of lubrication, VE distributor valve working piece, a variety of specifications of displacement for selection. The double outlet working piece (after the specification value of the working piece, the T represents the double outlet) has two oil outlets, which can be set as the side or upper output; the single outlet (after the specification value of the working piece, the S represents the single outlet) has one oil outlet, which can be at either end of the working piece, and the other end needs to be blocked. Note: that the double outlet working piece should not block any outlet, otherwise it will affect the normal operation. Magnetic and electronic proximity switch cycle indicators can be easily configured to provide positive protection for successful lubrication.
